> 5454 marine grade aluminum plate sheet

5454 As an aluminium-magnesium alloy, it combines moderate-to-high strength with excellent weldability. Like 5154, 5454 marine grade aluminum plate sheet is commonly used in welded structures such as pressure vessels and ships.

5454 is a sister alloy to 5083 with a lower rating to stress corrosion when functioning in the 150°F to 300 °F range. Typical uses are tankers, bodies, chemical handling tanks on vessels etc.

Alloy Grade: 5454
Temper: O, H111. H112, H24, H32, H34, H36, H38
Dimensions: T(1.5-120) X W(1000-3100) X (1000-13000)mm
Certificate: BV /DNV /ABS/Lioyds
Applications: Aluminum is the material of first selection of designers in high-speed ship, such as express ferries, LNG spherical tank type fluid reservoirs, hydrofoils, offshore working ships and yachts, and is widely used to shipboards, bottom plating, portholes, carrier plates and side plates of ship containers, etc.
Product Features: Long width, anti-corrosion, small elastic modulus, easy to welding, easy processing, without low temperature brittleness as well as non-magnetic.

Marine Aluminum Alloys Composition
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Ga	Others		Alu
											Each	Toal
5454	0.25	0.40	0.10	0.5-1.0	2.4-3.0	0.05-0.20	-	0.25	0.20	-	0.05	0.15	Remainder

5454 Marine Grade Aluminum Specification & Performance
Temper	Specified thickness(mm)		Rm MPa		Rp0,2 MPa		Elongation min. %		Bend radiusa		Hardness HBWa
Temper	over	up to	min.	max.	min.	max.	A50 mm	A	180°	9o°
Fa	≥2.5 120	120.0 150	215 205
O/H111	0.2	0.5	215	275	85		12		0.5t	0.5t	58
	0.5	1.5	215	275	85		13		0.5t	0.5t	58
	1.5	3.0	215	275	85		15		1.0t	1.0t	58
	3.0	6.3	215	275	85		17			1.5t	58
	6.0	12.5	215	275	85		18			2.5t	58
	12.5	50.0	215	275	85			16			58
H112	≥6.0	12.5	220		125		8				63
	12.5	40.0	215		90			9			59
	40.0	120.0	215		90			13			59
H12	0.2	0.5	250	305	190		3				75
	0.5	1.5	250	305	190		4				75
	1.5	3.0	250	305	190		5				75
	3.0	6.0	250	305	190		6				75
	6.0	12.5	250	305	190		7				75
	12.5	40.0	210	260	160			6			75
H14	0.2	0.5	270	325	220		2				81
	0.5	1.5	270	325	220		3				81
	1.5	3.0	270	325	220		3				81
	3.0	6.0	270	325	220		4				81
	6.0	12.5	270	325	220		5				81
	12.5	25.0	270	325	220			4			81
H22/H32	0.2	0.5	250	305	180		5		1.5t	0.5t	74
	0.5	1.5	250	305	180		6		1.5t	1.0t	74
	1.5	3.0	250	305	180		7		2.0t	2.0t	74
	3.0	6.0	250	305	180		8			2.5t	74
	6.0	12.5	250	305	180		10			4.0t	74
	12.5	40.0	250	305	180			9			74
H24/H34	0.2	0.5	270	325	200		4		2.5t	1.0t	80
	0.5	1.5	270	325	200		5		2.5t	2.0t	80
	1.5	3.0	270	325	200		6		3.0t	2.5t	80
	3.0	6.0	270	325	200		7			3.0t	80
	6.0	12.5	270	325	200		8			4.0t	80
	12.5	25.0	270	325	200			7			80
H26/H36	0.2	0.5	290	345	230		3				87
	0.5	1.5	290	345	230		3				87
	1.5	3.0	290	345	230		4				87
	3.0	6.0	290	345	230		5				87
H28/H38	0.2	0.5	310		250		3				93
	0.5	1.5	310		250		3				93
	1.5	3.0	310		250		3				93
For information only
